Heat Preservation Type Metering Pump
Heat preservation type metering pump is designed for conveying the medium thickened,solidification or crystallization under normal temperature,and maintained a certain temperature and easy flow,such as asphalt,paraffin wax,rosin,heavy oil,resin and similar liquid,the temperature is not higher than 280 ℃.
Send Inquiry
Product Introduction
Heat preservation type metering pump advantage
1. Unique design,interlinings are equipped in the main flow areas
2. Many seals to match application requirement
3. The drive motors diversity
Materials :Tool steel.cemented carbide
Stealing :Packing seal,Single and double mechanical seal
Installation :motor installation footing installation
Heat preservation type metering pump Performance Parameter Table
| Type | Single revolution displacement(cc/rec) | Rated flow at maximum speed (L/min) | Maximun speed(rpm) | Inlet/outlet dimensions |
| ES55 | 0.55 | 0.825 | 1500 | G1/4" |
| ES79 | 0.79 | 1.185 | 1500 | G3/8" |
| ES110 | 1.1 | 1.65 | 1500 | G3/8" |
| ES158 | 1.58 | 1.5 | 980 | G3/8" |
